Fellows 6A Type Gear Shaper Service Repair Manual Year (1961)
This Manual Covers Models:
6A-Type
65A3
62A3
624A3
61A
612A
615A
645A3
64A
624A
This Manual Includes:
-Adjusting Upper Worm and Worm Wheel for Correct Backlash
-Adjusting Lower Worm and Worm Wheel for Correct Backlash
-Centralizing Cutter and Work Spindles
-Aligning Cutter and Work Spindles
-Removing Cutter Slide Gear On Machine No 65A3 and 62A3
-Replacing Cutter Spindle Bushing and Testing Alignment of -Cutter Spindle On Machine Nos. 65A3, 645A3, 62A3, 624A3
-Adjusting The Relieving Mechanism
-Adjusting Apron Locking Mechanism
-Replacing Apron Pivots
-Checking Angle Block Setting
-Changing Angle Blocks To Change Angle Or Direction Of Apron Relief, Or Both
-Removing Work Spindle and Lower Index Wheel From Machine Nos. 61A, 612A, 615A, 62A3, 65A3
-Re Assembling Work Spindle and Lower Index Wheel On Machine Nos. 61A, 612A, 615A, 62A3, 65A3
-Removing Work Spindle And Lower Index Wheel From Machine Nos. 624A, 64A, 645A, 624A3, 645A3
-Re-Assembling Work Spindle And Lower Index Wheel On Machine Nos. 624A, 64A, 645A, 624A3, 645A3
-Removing And Replacing Apron Quill
-Adjustment Of Friction Clutch On Main Drive Shaft
-Repairing And Checking Feed and Timing Mechanism
This Manual Has 22 Pages.
Year 1961
