Monarch Series 10 CNC Lathe Programming Manual Year (1967)

Industrial Machinery Manuals Is Proud To Offer 1 Quality Bound Copy Of A: Monarch Series 10 Numerically Controlled Lathe Programming Manual Year (1967) This Manual Covers Models: Series 10 This Manual Includes: Pathfinder Lathes Safety Section A: General Machine Description Controlling the Tool Path Other Controlled Functions Machine Axis Nomenclature Section B: Organization for Numerical Control Section C: Program Planning Procedure Section D: Programming Methods Section E: Programming Procedure Section F: Condensed Coding and Special Instructions Section G: Tape Preparation Appendix: Speed Chart and Feed Chart Illustrations: Axis Nomenclature Organization Chart Numerical Control Drawing Eight-Station Turret Body Tooling Layout and Slide Travel Tool Location with Respect to the Spindle Center Line for Each of the Eight Commanded Positions Program Sheet Displacement of Tapers with Simplified Programming Method Taper of Workpiece Intersection of Tapers with Cuts Parallel to Machine Axis Tape Codes This Manual Has 105 Printed Pages. Drawings and Prints Year 1967
